LFP 51V 100Ah Solar Application Hybrid Inverter Battery

A high-performance 51.2 V 100Ah LiFePO₄ (LFP) Lithium Battery Pack designed for solar energy storage and hybrid inverter systems. Featuring advanced LiFePO₄ chemistry with integrated smart BMS, this 5.12 kWh battery offers long cycle life, reliable safety, wide compatibility with hybrid inverters, an

Electrical Specifications

• Operating Voltage Range: ~42 V – 57.6 V

• Fully Charged Voltage: ~58.4 V (typical)

• Discharge Cut-off Voltage: ~40 V – 44 V

• Standard Charge/Discharge Current: ~50 A – 100 A (depending on model & BMS)

• Max Continuous Discharge Current: up to ~100 A

• Peak Discharge Current: up to ~125 A short bursts (varies by design)

---

Battery Management System (BMS)

• Smart BMS with multiple protections:

  • Over-charge & over-discharge protection

  • Over-current protection

  • Short-circuit protection

  • Temperature management

  • Cell balancing functions

• Optional communication ports: CAN/RS485/RS232/Bluetooth (model dependent)

---

Performance & Life

• Cycle Life: ~6,000+ cycles @ 80 % DoD (typical)

• Depth of Discharge (DoD): up to ~95 % (model dependent)

• Operating Temperature:

  • Charge: ~0 °C to +45 °C

  • Discharge: ~-20 °C to +60 °C

• Self-Discharge: Low (months without significant loss)

---

Physical & Mechanical

• Typical Dimensions: ~600 × 440 × 168 mm (varies by brand)

• Weight: ~40–55 kg (model dependent)

• Protection Rating: IP20 or IP65 (depending on housing)

• Mounting Options: Wall mount, rack, or floor placement (model specific)

---

Features & Benefits

• 🔋 High Cycle Life: ~6,000+ cycles for long-term reliability in solar applications.

• ⚡ Smart Safety BMS: Multi-layer protection for safe charging/discharging.

• 📊 Communication & Monitoring: Optional CAN/RS485/RS232/Bluetooth integration for smart inverter systems.

• 🔌 Scalable: Multiple modules can be paralleled for larger storage systems.

• 🏡 Broad Compatibility: Works with most hybrid inverters that support 48 V/51.2 V lithium battery systems.

• 🌿 Maintenance-Free: LiFePO₄ chemistry requires no watering or equalization.

d scalable installation options. Ideal for home, commercial, and off-grid solar power systems.
